Marine engine VS Land engine: panoramic differences from "birth" to "service"
2025-08-06
Ⅰ. Introduction
The biggest difference between marine engine and land engine is not power but environmental adaptability and regulatory compliance. The marine engine shall be operated reliably for a long time in salt spray, swaying and closed cabins and follows emissions,. The land engine mainly focuses on noise, costs. The following is a systematic analysis of the differences from aspects of seven dimensions.
Ⅱ. Environmental Adaptability：Marine VS Land
| Dimension | Marine engine | Land engine | New trends in 2025 |
| Anti-corrosion | Epoxy zinc-rich primer + polyurethane topcoat ≥120 μm, 316L stainless steel, copper-nickel alloy seawater pipeline; salt spray test ≥500 h | Ordinary anti-corrosive paint ≤80 μm, suitable for 304 stainless steel; salt spray test 200 h
| IMO 2024 draft guidelines include the assessment of “biological corrosion” for the first time, requiring marine engines to add microbial corrosion-resistant coatings. |
| Insulation | F/H grade heat-resistant insulation, capable of long-term operation at 95% humidity and 150°C; epoxy potting ends | B/F grade insulation, suitable for environments with 80% humidity; tied fixing ends | IEC 60092-301:2024 increase insulation resistance allowable attenuation rate of marine engine after vibration from 20% to 15% |
| Sealing | Control box starts at IP56 and cabin keeps at IP67 | Most are IP23 and outdoor models are up to IP54
| The new national standard of Land engine: GB/T 2820.First proposal for "coastal type" IP55 selection standard in October 2024. |
Ⅲ. Mechanical structure: damping and shock resistance
- Marine Engines
- Base:Multi-layerscomposite vibration damper (spring + damping + rubber) +more than 10 mm overall welded frame, absorbing more than 80% of 1–10Hz low-frequency vibration energy
- Piping:Bellows with flexible joints to prevent weld fatigue.
- Testing:Sine and shock bispectral testing,10g transient impact simulation of huge wave collision
- Land Engines
- Base: Rubber pads or simple springs with 30–50% vibration reduction.
- Piping:Rigid flange mainly.
- Testing: Only perform self-oscillation frequency response test within 5g.
Ⅳ. Emissions and regulations: IMO Tier III and Euro V and National IV
| Object | Current regulations | 2024–2026 Nodes | Remark | |
| Main engines for international vessels | IMO Tier III (NOx <3.4 g/kWh) | The Tier IV draft (<1.5 g/kWh) may be implemented from 2025, requiring SCR+EGR combination | A communication working group has been established at the 2024.7 MEPC 81 meeting | |
| Inland/offshore marine engines | China Phase II (GB 15097-2022) | Phase III will be implemented from July 2025, NOx <4.0 g/kWh | Onboard monitoring (OBM) is required for the first time | |
| Non-road land engine | National IV | Beijing/Shanghai etc. 5 cities will pilot National V.from December 2024 | National V may introduce PN (particle number) limits | |
Ⅴ. Maintenance: Space, Cycles, and Spare Parts
- Space:The cabin is about 2 meters high.The distance from the top of the engine to the deck is only 30–50 cm. Therefore, the oil and fuel filter of the marine engine are all side-mounted or remotely located. The land engine can be maintained from the top.
- Cycle: Replace marine lubricant oil every 250 hours (ocean-going) and 125 hours (short-haul) and Land engine every 500–800 hours.
- Spare Parts: CCS certified "equivalent spare parts" must be carried on board.Otherwise,the ship may be detained during PSC inspection.There is no mandatory requirement for Land engine.
- New Trend in 2024: Marine engine manufacturers (Cummins, MAN) are beginning to incorporate "digital twins" into CCS guidelines. Predict remaining oil replacement intervals through AI can reduce maintenance frequency by 10–15%.
VI. Fuel and Lubrication: High-Sulfur Heavy Fuel Oil VS Light Diesel Oil
- Marine low-speed two-stroke engines:Use HFO (380 cSt/50°C) with a sulfur content up to 0.5% (as per the 2020 global sulfur cap).The desulfurizer or low sulfur fuel oil is required.
- Marine middle high speed auxiliary engines: Generally use MGO/MDO.
- Land diesel engines: The sulfur content must be ≤10 ppm after National IV.SCR requires urea. Lubricants: Marine engines use cylinder oil with a BN (base number) as high as 70 mgKOH/g to neutralize the acidity of HFO.For Land engines, diesel engine oil with BN 10–15 is sufficient.
Ⅶ. Certification and Market Access
| Certification | Marine engine | Land engine |
| International | Classification Society Certificate such as ABS, LR, DNV, BV, KR, NK, and RINA | No mandatory classification society requirements |
| Domestic | CCS "Rules for Classification of Sea-Going Steel Ships" + marine product inspection | GB/T 2820, GB 20891, ISO 9001 |
| New in 2024 | IACS Rec. 2024 (Uniform Software Cybersecurity Requirements) | The national standard is drafting the "Basic Requirements for Cybersecurity of Mobile Machinery Network Security" |
Ⅷ. Summary
Marine engines are customized power for the severe marine environment and global strictest emission regulations with high corrosion resistance, high reliability and high regulatory costs.Land engines are more like industrial products designed for high volume, low cost, and gradually evolving regulations. When selecting an engine, determine the environment first, then check the regulations and finally consider the power.
